ETS PA830 AES/EBU 110 Ohm Digital Audio Splitter XLRF to 2 X

The ETS PA830 Series are the Balanced Line™ Digital Audio Splitters and Digital Audio Splitter Panels. These products are expressly designed for the digital audio market. Used only for balanced 110 Ohm signals, these units accommodate signal levels to 10V. Since proper impedance is maintained, the splitters do not have to be symmetrically applied. Due to careful specification and minimal signal modification, these units may be cascaded reducing transmitted signal power by 3 dB at each stage. New to the product line is the PA835 that is a panel-mounted splitter in 4 channel version.

Features

Devices are used for splitting AES/EBU digital audio signals Eliminates the need for a distribution amplifier in many applications Superb impedance matching Rugged metal cases and chassis Made in USA. 100% QA.

Specifications

Bandwidth: 200 kHz to 10 MHz Connectors: (3) XLR per channel Impedance: 110 Ohm Insertion Loss: < 0>

资料下载

PA830-Specifications

PA832-Specifications

PA835-Specifications
